Basket Filter and Strainers

Basket Filter and Strainers are uniquely designed filtration solutions suitable for demanding applications such as sea water desalination and handling of heavy acid and alkali chemicals. The robust housing design ensures reliable performance under high flow and pressure conditions.

Manufactured using a wide range of materials including mild steel or carbon steel with rubber or FRP lining, as well as duplex and super duplex stainless steel, these filters are engineered to meet specific process requirements. Custom-built designs are available to handle flow rates up to 1000 m³/hr.

null

Proven performance in demanding environments

Reliable performance in harsh industrial environments.

null

Low operating and maintenance costs

Optimized for efficient operation with low maintenance and reduced costs.

null

Custom-built solutions as per application needs

Designed to meet specific application needs for optimal performance.

null

Trusted quality and consistent results

Built with high-quality materials for dependable and consistent performance.

Key Features

  • Unique design suitable for sea water desalination and corrosive chemical applications
  • Available in mild steel or carbon steel with rubber or FRP lining
  • Duplex and super duplex stainless steel construction options
  • Filter internals available in various materials to suit end applications
  • Available in different design pressure ratings
  • Multiple inlet and outlet connection options
  • Custom-designed housings available
  • Designed to handle flow rates up to 1000 m³/hr

Applications

  • Power plants
  • Process industries
  • Cement plants
  • Steel industries
  • Petrochemicals
  • Fertilizers
  • Refineries
  • Oil and gas
  • Chemical industries
  • Textile industries

Technical Data

Parameter Details
Flow Rate Up to 1000 m³/hr, more on request
Design Code Good Engineering Practice, ASME section VIII Division 1
MOC MS, CS, Duplex 2205, Super Duplex 2507
Pressure Rating 1 – 15 bar
Temperature Rating -25°C to +65°C, more on request
Connection Size 4” – 20”
Connections Flange
Vessel Closure TC Clamped, Bolted
Sealing Material Silicon / Neoprene / EPDM / NBR / PTFE / Teflon / Viton
Lifting Device Davit Arm, Lifting Lug, Lifting Handle
Vessel Support Legs, Skirt
Surface Finish Matt Finish, Mirror Finish, Paint
Optional Finish Rubber/FRP Lining and/or Painting
Customized Design Available in customized design to accommodate specific requirements
Accessories (Optional) Pressure Gauge, Vent Valve, Drain Valve, D.P. Gauge
